32″ 4K UHD 3D Medical Monitor

32″ 4K UHD 3D Medical Monitor

JENSHI 32″ 4K 3D Medical Monitor provides high-resolution, high-contrast, wide-color gamut, and wide-viewing-angle 3D medical image.

  • Product Details



JENSHI 32″ 4K UHD 3D  Medical Monitor






Features:

4K UHD Resolutions / FHD Automatically Upscaling

High quality 4K resolution (3840 x 2160 pixels) image on 32-inch screen.FHD input signal is acceptable, and there solutions will upscale automatically into 4K resolution.

Support various 3D formats

JENSHI monitor supports various 3D formats including Line-by-ine, Side-by-side and Top & bottom through all thel / 0inter faces such as 12G SDl, 3G SDI, DVI, DP, HDMl …etc.

High contrast ratio and brightness

High contrast and high brightness technologies can make the depth of field more obvious and clearer,  also provide clear details of tissue during surgeries, so that the doctor can operate the movements more efficiently.

Deep Red Technology

With advanced Deep Red technology for optimized display of red colors provide physicians with the most realistic color sand details.

2D multi-image display modes

The monitor can display multiple images simultaneously in 2D mode.  For picture-out-picture(POP), user can choose to display 2images or 4images together;  for picture-in-picture (PiP) , 2 images can be displayed.

Easy to clean and waterproof

The monitor is easily cleaned, the smooth surface and lP 65 water proof front housing allow you to easily wipe the screen with sanitizer and remove the dirt and stains.

Wide 3D vertical view in gangle

Widest 3D vertical viewing angle could provide good image quality to OR team members with different heights (from 140-190 cm),reduce the crosstalk phenomenon during the surgery, enhance the safety and efficiency.



Technical Specifications:



Contrast Ratio (typ.)

1500:1

Brightness (typ.)

Typ.:600 cd/m2 calibrated

Response Time (Typ. ms)

22 msec (Tr. + Tf)

Viewing Angle

178° Hor./178°
3D Vertical Viewing Angle Optimal viewing distance: 33° Up/Down (crosstalk< 7%)
3D Viewing Distance

Optimal:>1500 mm; Minimum:700 mm

Lens Type

Circular polarization : Right eye on top

LED Life (hrs)

30K (min.)

Support Color

True 10-bit

Color Gamut

DCI-P3 98%

Power Consumption (Max., W)

On:< 150 W, Standby:< 40 W

Power Supply Voltage (V)

100V -240V

Operation Temp (C)

0°C~+40°C

Storage Temp (°C)

-20°C~+60°C
